Aanzuigvolume [l/min]                 900 l/min
Aanzuigvolume [m³/uur]             54 m³/uur
Ketelinhoud                                      300 liter
Maximale druk                                 11 bar
Werkdruk [bar]                                9 bar
Motorvermogen [pk]                    7,5 pk
Motorvermogen [kW]                  5,5 kW
Toerental                                           1000 tpm
Geluidsniveau [dB(A)]                   76 dB(A)
Voltage                                               400 V
Frequentie                                        50 Hz
Fase                                                      3 ~
Stroomopname                                8,6 A
Thermisch beveiligd                       Ja
Stekker                                               Geen
Smering                                              Oliegesmeerd
Cilinders                                              2
Aantal wielen                                   Geen
Vliegwiel Diameter                         400 mm
V-snaar                                               B70
Electromotor Toerental                2850 tpm
Compressorpomptype                  K 30

Lengte                 1760 mm
Breedte [mm]   720 mm
Hoogte [mm]    1150 mm
Gewicht              170 kg
